Specifications
| System-Configuration | XT-8317 |
| Processor |
Intel Tiger Lake UP3 Core i3-1115G4E, up to 3.90 GHz, 6M Cache; Intel Tiger Lake UP3 Core i5-1145G7E, up to 4.10 GHz, 8M Cache; Intel Tiger Lake UP3 Core i7-1185G7E, up to 4.40 GHz, 12M Cache |
| System Memory | DDR4 SO-DIMM slot x 2, max. 64GB |
| Storage Device | M.2 connector x 2 (support both SATA and PCIe signal) |
| RAID Function | Yes , (RAID 0/1) |
| Intel vPro Support | Yes, depends on processor |
| TPM | TPM 2.0 |
| Power Supply | 12V/84W |
| OS Support | Windows 10 IoT LTSC Windows 11 IoT LTSC |
| Display & Touch | |
| LCD | 17” TFT LCD |
| Resolution | 1280 x 1024 |
| Touch | True-flat PCAP touch with multi-touch support (IP65 on front panel) |
| I/O Expansion | |
| Serial Port | RJ50 x 4 + COM5/COM6 via optional converter cable from service window, 5V support on all COM ports, 12V support on COM 1 to COM 4 |
| Parallel Port | via optional conversion cable through service window |
| Standard USB Port | USB 3.0 x 4 + USB 2.0 x 4 |
| PoweredUSB Port | Optional 24V x 1 + 12V x 3 via GEN8E base |
| OTG USB | N/A |
| LAN Port | 10/100/1000 Mb x 2 |
| Display Port | VGA x 1 (12V support for Posiflex monitors) + HDMI x 1 |
| CR Port | RJ11 x 1, control 2 CR via optional Y-cable, support 24V cash drawer |
| PS2 Port | via optional conversion cable through service window |
| UPS Port | Yes, for optional UPS battery |
| Audio | Internal 2W speaker x 1 + Line-out/mic-in combo jack x 1 |
| Expansion Slot | M.2 slot x 1 |
| Dimension | |
| Dimension (W x D x H in mm) | 404 x 251 x 355 |
| Weight (N. W. in kg) | 7.2 |
| Environmental | |
| Operating Condition | 0°C - 40°C, 20%RH - 90%RH |
| Storage Condition | -20°C - 70°C, 10%RH - 90%RH |
| Built-In Options | |
| WiFi module | M.2 WiFi/BT module |
| Camera Module | N/A |
| Printer Module | N/A |
| AG Glass | N/A |
| Attachment Options | |
| POS Monitor | PCAP touch TFT LCD: 9.7"/14"/15" Non-touch TFT LCD: 7"/9.7"/12.1"/14"/15" Resistive touch TFT LCD: 15" |
| Line Display | 2 x 20 rear-mount VFD/LCD customer line display; 7" color LCD graphical customer line display |
| External UPS Pack for RT Series | N/A |
| Attachment | MSR; iButton; Rotatable 2D Scanner; RFID; Fingerprint Sensor; Keypad, 24V + 12V PoweredUSB module via GEN 8E base (USB 2.0 x 1 will be occupied with this module) |
| Note | - |
*product specifications and model configurations are subject to change and may vary by global region.
