TX 5000+

System-Configuration

TX 5000+

Processor

Intel Tiger Lake UP3 Core i3
Intel Tiger Lake UP3 Core i5
Intel Tiger Lake UP3 Core i7

System Memory

2 x DDR4 SO-DIMM, max. 64 GB

Storage Device

M.2 connector x 2 [Support both SATAIII and PCIe signal]

RAID Function

Yes

TPM

TPM 2.0

Power Supply

12V/60W

OS Support

Windows 10 IoT LTSC
Windows 11 IoT LTSC

I/O Expansion

Serial Port

DB9 x2 + RJ-50 x2 + COM5/COM6 via optional converter cable from service window, 5V/12V support on all COM ports

Parallel Port

N/A

Standard USB Port

Rear: 4 x USB 3.2 Gen2x1 + 3 x USB 2.0
Front: 2 x USB 2.0

PoweredUSB Port

N/A

OTG USB

N/A

LAN Port

10/100/1000 Mb x2

Display Port

VGA x1 , 12V support for Posiflex monitors + HDMI (2.0) x2

CR Port

RJ11 x1, control 2 x cash drawer, support 24V CR

PS2 Port

N/A

Audio

2W speaker x1+ mic-in/line-out x1

Expansion Slot

M.2 2230 for Wi-Fi/BT

Dimension

Dimension (W x D x H in mm)

220 x 202 x 83

Weight (N. W. in kg)

2.75Kg

Environmental

Operating Condition

0°C - 40°C, 20%RH - 90%RH

Storage Condition

-20°C - 70°C, 10%RH - 90%RH

Built-In Options

WiFi module

N/A

Camera Module

N/A
