System-Configuration |
PS-6216 |
|
Processor |
Intel TGL Core i3 |
|
System Memory |
DDR4 SO-DIMM x 2, max. 64 GB |
|
Storage Device |
M.2 SSD [Support SATAIII signal] x 1 |
|
Intel vPro Support |
Yes, depends on CPU installed |
|
TPM |
TPM 2.0 |
|
OS Support |
Windows 10 IoT LTSC / Windows 11 IoT LTSC |
|
Display & Touch |
|
|
LCD |
15.6” TFT LCD with LED backlight |
|
Resolution |
1366 x 768 |
|
Touch |
True-flat PCAP touch with multi-touch support (IP65 on front |
|
I/O Expansion |
|
|
Serial Port |
DB9 x 2 (on I/O plate) + RJ50 x 1 (on the top), 5V/12V support on |
|
Standard USB Port |
USB 3.0 x 4 + USB 2.0 x 2 (on I/O plate) + USB 2.0 x 1 (on the |
|
LAN Port |
10/100/1000 Mb x 1 |
|
Display Port |
HDMI x 1 |
|
CR Port |
CR port x 1, control 2 x CR via optional Y-cable, support 24V CR |
|
Audio |
Internal 2W speaker x 1 |
|
Expansion Slot |
1 x M.2 2230 for Wi-Fi/BT |
|
Dimension |
|
|
Dimension (W x D x H in mm) |
371.35 x 252 x 290.4 |
|
Environmental |
|
|
Operating Condition |
0°C - 40°C, 20%RH - 90%RH |
|
Storage Condition |
-20C - 70C, 10%RH - 90%RH |
*product specifications and model configurations are subject to change and may vary by global region.
